Aerial

TypeRoof

Bumpers

ColourPainted

Tyres

Tyre Width175

Tyre Profile60

TypeConventional

Official Brochure Tyre SizeYes

Paint

TypeGloss

Door mirrors/cameras

TypeElectrically Adjustable

ColourPainted

Rear windscreen

TypeFixed

WipersIntermittent

Wheels

Rim TypeAlloy

Rim Diameter (in)14

Rim Width (in)5

Spare wheel

TypeSpace Saver

Rim TypeSteel

Non-corrosive body

TypeGalvanised

External dimensions

Overall Length (mm)3565

Overall Width (mm)1595

Overall Height (mm)1540

Wheelbase (mm)2380

Front Track (mm)1400

Rear Track (mm)1385

Kerb To Kerb Turning Circle (mm)4750

Overall Length (in)140.4

Overall Width (in)62.8

Overall Height (in)60.6

Wheelbase (in)93.7

Front Track (in)55.1

Rear Track (in)54.5

Kerb To Kerb Turning Circle (ft)15.6

Load compartment capacity

Rear Seat Up To Lower Window (l)225

Rear Seat Down To Roof (l)889

Rear Seat Up To Lower Window (cu Ft)7.9

Rear Seat Down To Roof (cu Ft)31.4

Fuel tanks

TypeMain

Capacity (l)35

Capacity (gal)9.2

Capacity (UK Gallons)7.7

Weights

Gross Vehicle Weight (kg)1430

Published Kerb Weight (kg)1020

Gross Trailer Weight Braked (kg)700

Gross Vehicle Weight (lbs)3153

Published Kerb Weight (lbs)2249

Gross Trailer Weight Braked (lbs)1543

Disc brakes

Number Of4

Number Of Ventilated Discs2

Headlights

Bulb Type (low Beam)Halogen

Headlight control

Height AdjustmentManual

Front airbag

Occupant Switch OffYes

Head restraints

Height AdjustableYes

Number3

Front seat belts

Seat PositionPassenger

Pre-tensionersYes

Height AdjustableYes

Rear seat belts

Seat PositionCentre

Type3-point

Engine

Cc1248

Litres1.2

Bore71

Stroke78.8

Compression Ratio10.5

Number Of Cylinders4

ConfigurationIn-line

Valve Gear TypeDouble Overhead Cam

Number Of Valves Per Cylinder4

Emission control level

Standard MetEU4

CO2 Level - G/km Combined139

CO (g/km)0.511

HC (g/km)0.036

HC + NOx (g/km)0.053

NOx Level (g/km)0.017

Fuel system

Injection/carburationMulti-point Injection

Fuel

Fuel TypeUnleaded

Fuel Type Octane No.95

Generic Primary Fuel TypePetrol

Performance

Maximum Speed (km/h)156

Acceleration 0-62mph (s)14.4

Maximum Speed (mph)97

Power

Measurement StandardEEC

Maximum Power KW57

Maximum Power Hp/PS77

Rpm For Maximum Power (low)6000

Maximum Torque Nm118

Rpm For Maximum Torque (low)4000

Power steering

TypeElectric

Suspension

TypeTorsion Beam

Anti-roll BarYes

Wheel DependenceSemi-independent

Spring TypeCoil

Traffic light coding

Efficiency LabelE

Main service

Distance (km)16093

Period (mths)12

Distance (miles)10000

Fuel consumption

StandardECE 99/100

Urban (l/100km)7.3

Country/highway (l/100km)5.1

Combined (l/100km)5.9

Urban (km/l)13.7

Country/highway (km/l)19.6

Combined (km/l)16.9

Urban (mpg)32

Country/highway (mpg)46

Combined (mpg)40

Urban (miles Per UK Gallon)39

Country/highway (miles Per UK Gallon)55

Combined (miles Per UK Gallon)48

Powertrain type

TypeCombustion
